10kw IP23soundproof Diesel Generator Brushless Diesel Generator
Control system:
1. Automatic alarm system: the unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current.
2. Operation display:
a) Unit voltage, tri-phase load current and frequency display
b) Water temperature, oil pressure display
c) Fuel level, fuel temperature display
d) Audible and visual alarm lamps and buzzers
Accessories:
1) Standard accessories: Standard 40 radiator mounted on skid, Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, Standard tools kit, operation manual and document.
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, communiCAT-parts-partsion interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.
Quality control of Genor Power Genset:
1.The genset canopy can be designed by customers demand free of charge.
2.Noise level can be designed by customer demand, standard noise level is 70-73DB at 7m. Super silent is 60-65DB at 7m.
3.Canopy color can be painted free of charge by customer demand. It is high quality paint.
4.All connection components and door lock are stainless steel.
5. We added oil filling inlet with lock
6.The oil box is separate made and then welded to the base frame, not by simple welding on the base frame. It is to make sure there is no oil leakage
7.The base frame is with forklift mouth which is easy to load and discharge
8. For Logo, we can paint customer's logo when the order is more than 5 sets.
9. For technical specifiCAT-parts-partsion or question, we can support you by our strong technical team
Engine Data:
| Manufacturer / Model: | DCEC Cummins 6CTA8.3-G2, 4-cycle |
| Air Intake System: | Turbo, Water/Air Cooling |
| Fuel System: | PB/W type fuel pump |
| Cylinder Arrangement: | 6 in line |
| Displacement: | 8.3L |
| Bore and Stroke: | 114*135(mm) |
| Compression Ratio: | 17:1 |
| Rated RPM: | 1500rpm |
| Max. Standby Power at Rated RPM: | 180KW/244HP |
| Governor Type: | Electronic |
| Exhaust System |
| Exhaust Gas Flow: | 34.7m3/min |
| Exhaust Temperature: | 570℃ |
| Max Back Pressure: | 10kPa |
| Air Intake System |
| Max Intake Restriction: | 6kPa |
| Burning Capacity: | 12.4m3/min |
| Air Flow: | 238m3/min |
| Fuel System |
| 100%( Prime Power) Load: | 215 g/Kw.h |
| 75%(Prime Power) Load: | 211 g/Kw.h |
| 50%(Prime Power) Load:: | 216 g/Kw.h |
| 100%( Prime Power) Load: | 39.7L /h |
| Oil System |
| Total Oil Capacity: | 23.8L |
| Oil Consumption: | ≤4g/kwh |
| Engine Oil Tank Capacity: | 18.9L |
| Oil Pressure at Rated RPM: | 276-414kPa |
| Cooling System |
| Total Coolant Capacity: | 34L |
| Thermostat: | 82-95℃ |
| Max Water Temperature: | 104℃ |
